1U Rackmount Chassis- OC125L-M
• Compatible with the Mirco-ATX form factor
| • 2 front pre-installed cooling fans inside to provide excellent airflow and thermal protection system
| • Widely used in the fields of automation, equipment manufacturing, power monitoring, communication, security, and defense
| > Power Supply not include
Description
Package Information
Inquiry
| Model: | OC125L-M (Barebone System) |
| 1U Rackmount Chassis: | D250 × W482 × H44.5 mm |
| Material: | 1.0 mm SGCC; Aluminum panel |
| MB Compatibility: | 7″ x 7″ (170 x 170 mm) |
| PSU Form Factor: | 1U flex power |
| Fan Configuration: | 2* 4020 Fan |
| HDD Bay: | 3* 3.5-inch Hard Disk, or 2* 2.5-inch &1* 3.5-inch Hard Disk |
| CD-ROM: | None |
| Expansion Slot: | 1 High straight slot (with switching card / sold separately) |
| Front Panel Control: | 2* USB2.0; 1* Power Switch, 1* Reset Switch; 1* Power Indicator, 1* HDD Indicator |
| Net Weight: | 2.55 kg |
| Gross Weight: | 3.65 kg |
| Packaging Size: | 54 * 38.5 * 14.5 cm (0.03 CBM) |
| Container Loading Qty: | 20GP: 900; 40GP: 1,870; 40HC(HQ): 2,190 |
| Operaing Temperature: | 10°C-35°C (without direct light); Extended operating temperature: 5°C-40°C (restrictive configuration satisfied); Storage temperature: 20%-90% |
Transportation & Storage Temperature: | -40°C-70°C |
| Net Weight: | 2.55 kg |
| Gross Weight: | 3.65 kg |
| Packaging Size: | 54 * 38.5 * 14.5 cm (0.03 CBM) |
| Container Loading Qty: | 20GP: 900; 40GP: 1,870; 40HC(HQ): 2,190 |
