2U Rackmount Chassis- OC265F-M
• Compatible with the EATX form factor
| • 4 front pre-installed cooling fans inside to provide excellent airflow and thermal protection system
| • Widely used in the fields of automation, equipment manufacturing, power monitoring, communication, security, and defense
| > Power Supply not include
Description
Package Information
Inquiry
| Model: | OC265F-M (Barebone System) |
| 2U Rackmount Chassis: | D650 × W482 × H89 mm |
| Material: | 1.2 mm SGCC |
| MB Compatibility: | 12″ x 13″(305*340 mm) |
| Fan Configuration: | 4* 8025 Fan |
| PSU Form Factor: | Ordinary Desk-type ATX Power Supply PS2 |
| HDD Bay: | 8* 3.5-inch Hard Disk |
| CD-ROM: | 2* 5.25-inch CD-ROM Drive |
| Expansion Slot: | 7* Full-Height PCIE Slot |
| Front Panel Control: | 2* USB2.0; 1* Power Switch, 1* Restart Switch; 1* Power Indicator, 1* HD Indicator |
| Net Weight: | 9 kg |
| Gross Weight: | 11 kg |
| Packaging Size: | 78 * 55 * 17.5 cm (0.075 CBM) |
| Container Loading Qty: | 20GP: 383; 40GP: 794; 40HC(HQ): 930 |
| Operaing Temperature: | 10°C-35°C (without direct light) ; extended operating temperature: 5°C-40°C (restrictive configuration satisfied); storage temperature: 20%-90% |
| Transportation & Storage Temperature: | -40°C-70°C |
| Net Weight: | 9 kg |
| Gross Weight: | 11 kg |
| Packaging Size: | 78 * 55 * 17.5 cm (0.075 CBM) |
| Container Loading Qty: | 20GP:383; 40GP: 794; 40HC(HQ): 930 |
