2U Rackmount Chassis- OC239F-M
• Compatible with the Marco-ATX form factor
| • 2 front pre-installed cooling fans inside to provide excellent airflow and thermal protection system
| • Widely used in the fields of automation, equipment manufacturing, power monitoring, communication, security, and defense
| > Power Supply not include
Description
Package Information
Inquiry
| Model: | OC239F-M (Barebone System) |
| 2U Rackmount Chassis: | D390 × W482 × H89 mm |
| Material: | 1.2 mm SGCC |
| MB Compatibility: | 9.6″ x 9.6″(245*245 mm) |
| Fan Configuration: | 2* 8025 Fan |
| PSU Form Factor: | Ordinary Desk-type ATX Power Supply PS2 |
| HDD Bay: | 4* 3.5-inch Hard Disk |
| CD-ROM: | 2* 5.25-inch CD-ROM Drive |
| Expansion Slot: | 4* Half-Height PCIE Slot |
| Front Panel Control: | 2* USB2.0; 1* Power Switch, 1* Restart Switch; 1* Power Indicator, 1* HD Indicator |
| Net Weight: | 5 kg |
| Gross Weight: | 6.5 kg |
| Packaging Size: | 54 * 52 * 17 cm (0.05 CBM) |
| Container Loading Qty: | 20GP: 560; 40GP: 1,160; 40HC(HQ): 1,360 |
| Operaing Temperature: | 10°C-35°C (without direct light); extended operating temperature: 5°C-40°C (restrictive configuration satisfied); storage temperature: 20%-90% |
| Transportation & Storage Temperature: | -40°C-70°C |
| Net Weight: | 5 kg |
| Gross Weight: | 6.5 kg |
| Packaging Size: | 54 * 52 * 17 cm (0.05 CBM) |
| Container Loading Qty: | 20GP: 560; 40GP: 1,160; 40HC(HQ): 1,360 |
