2U Rackmount Chassis- OC235L1-M
• Compatible with the Marco ATX form factor
| • Apply high-quality Ma Steel flowers-free zinc plating and aluminum panel
| • Solid, compact, reasonable in design, and easy to install and operate
| • Widely applied in different sectors, including industrial automation, communication, electricity, network safety, intelligent transportation, video surveillance, medical care, etc.
| > Power Supply not include
Description
Package Information
Inquiry
| Model: | OC235L1-M (Barebone System) |
| 2U 19" Rackmount Chassis: | D350 × W482 × H89 mm |
| Material: | 1.2 mm SGCC; Aluminum panel |
| MB Compatibility: | 9.6″ x 9.6″ (245 x 245 mm) |
| PSU Form Factor: | ATX Power Supply |
| Fan Configuration: | 2* 8025 Fan |
| HDD Bay: | 3* 3.5-inch Hard Disk, or 2* 2.5-inch & 1* 3.5-inch Hard Disk |
| CD-ROM: | None |
| Expansion Slot: | 4* Half-Height PCIE Slot |
| Front Panel Control: | 2* USB2.0; 1* Power Switch, 1* Reset Switch; 1* Power Indicator, 1* HDD Indicator |
| Net Weight: | 4.3 kg |
| Gross Weight: | 5.8 kg |
| Packaging Size: | 54 * 48 * 18 cm (0.046 CBM) |
| Container Loading Qty: | 20GP: 608; 40GP: 1,260; 40HC(HQ): 1,478 |
| Operaing Temperature: | 10°C-35°C (without direct light); Extended operating temperature: 5°C-40°C (restrictive configuration satisfied); Storage temperature: 20%-90% |
| Transportation & Storage Temperature: | -40°C-70°C |
| Net Weight: | 4.3 kg |
| Gross Weight: | 5.8 kg |
| Packaging Size: | 54 * 48 * 17 cm (0.044 CBM) |
| Container Loading Qty: | 20GP: 608; 40GP: 1,260; 40HC(HQ): 1,478 |
