2U Rackmount Chassis- OCR240-T
• High-quality steel and compliant with EMC design standards
• Support Micro-ATX and ATX motherboards
• 2 front pre-installed cooling fans inside to provide excellent airflow and thermal protection system
• Support both PS2 and 1U power supplies
• Widely used in Cloud computing and cloud rendering; Security monitoring systems; IoT and edge computing platforms; Network storage and data processing; Industrial control systems
Description
Package Information
Inquiry
| Model: | OCR240-T (Barebone System) |
| 2U Rackmount Chassis: | D430 × W400 × H88 mm |
| Main Material: | Quality fine 1.0 mm SGCC steel |
| Color: | Black |
| Drive Bay: | Support 4* 3.5" HDD drive bays, 1* 5.25" CD-ROM bay |
| Cooling Fan: | Front 2* 80mm fan |
| Expansion Slot: | 4* PCI expansion slot / 7* PCI expansion slot |
| MB Compatibility: | 4-slots supports Micro-ATX 9.6" x 9.6" motherboard; 7-slots supports ATX 12" x 9.6" motherboard |
| PSU Form Factor: | 4-slots rear panel with PS2 power supply; 7-slots rear panel with standard 1U power supply |
| Connector: | 2* front accessible USB2.0 port |
| System Control: | 2* USB2.0; 1* Power Switch, 1* Restart Switch; 1* Power Indicator, 1* HD Indicator |
| Applicarion: | Cloud computing, cloud rendering, security monitoring, IoT, etc. |
| Operation Temperature: | 10°C-35°C (without direct light); Extended operating temperature: 5°C-40°C(restrictive configuration satisfied); Storage temperature: 20%-90% |
| Transportation & Storage Temperature: | −40 °C – 70 °C |
