2U 24* HDD Rackmount Server Chassis -OCS2650U-H24-T
• 8 × 3.5" (or 10 x 2.5") hot-swappable drive bays
• 13.9" x 13" motherboards, supporting EATX & smaller form factors
• 2U standard, 1 + 1 CRPS
• 6Gb/12Gb direct backplane connection (optional SFF-8087 or SFF-8643 cabling)
• 7 half-height PCI cards; Full EMI/EMC shielding design; Multiple rear I/O panel
Description
Package Information
Inquiry
| Model: | OCS2650U-H24-T (NVMe) | |
| 2U Server Chassis: | 650 (D)*437.5 (W)*88 (H) mm; Rackmount style | |
| Material: | Medium steel, environmental protection, anti-fingerprint 1.0 mm SGCC | |
| Surface Treatment: | Handle and hanging lugs are sandblasted and oxidized to bright black, and other steel plates are of natural color | |
| HDD Backplane: | 12Gb NVME directly connected to the backplane, with fan temperature control and speed regulation, with SGPIO | |
| HDD Support: | 24* front 2.5″ NVME U.2, 2 rear 2.5″ HDD/SSD (NVME optional), support hot swap | |
| I/O Expansion: | 7 Half height PCle expansion slots | |
| SGPIO: | √ | |
| System Cooling Fans: | 4 *8 cm fan positions, 3*(8038) fans as standard, support hot swap | |
| Applicable Motherboard: | 12″ x 13″(E-ATX) and below motherboard | |
| Applicable PSU: | Compatible with standard 2U power supplies and CRPS redundant power supplies with a length of 240mm and below | |
| External Interface: | USB2.0 *2 | |
| System Control: | 1* Power LED, 1* Reset, 1* Power SW, 1* HDD LED, 2* NIC LED, 1* UID SW, 1* UID LED, 1* OH/FAN FAIL LED, 1* POWER FAIL LED | |
| Packing Info: | Pearl cotton + inner box + outer box | |
| Applicable Field: | Video clips, cloud storage, big data, and other fields | |
| Operaing Temperature: | 10°C-35°C (without direct light); extended operating temperature: 5°C-40°C (restrictive configuration satisfied); storage temperature: 20%-90% | |
| Transportation & Storage Temperature: | -40°C-70°C | |
