4U GPU Server Chassis -OCG4680-4H8-H
✅ 4U rackmount server chassis with robust SGCC steel construction
✅ Broad motherboard compatibility
✅ Large storage capacity
✅ GPU-ready architecture
✅ 11 PCI expansion slots for maximum scalability
✅ Efficient cooling system
✅ Redundant PSU support for enterprise reliability
✅ Easy deployment with optional tool-free slide rail design
Description
Package Information
Inquiry
| Model: | OCG4680-4H8-H (Barebone System) | |
| 4U 4GPU Server Chassis: | 680(D) x 436(W) x 176(H) mm | |
| Material: | Taiwan sinosteel SGCC 1.2 mm | |
| M/B Form Factor: | MAX(13.9" x 13")/EEB(12" x 13")/CEB(12" x 10.5")/ATX(12" x 9.6")/Mini-ATX(11.2" x 8.2")/Micro-Atx(9.6" x 9.6")/ITX(7" x 7") | |
| PSU Form Factor: | Single 2U, 1+1 Redundant PSU, ATX, CRPS | |
| HDD Backplane: | 6Gb/12Gb SATA/SAS direct Backplane(SFF-8087/SFF-8643 cable for optional) | |
| HDD Support: | Support 8* 3.5" hot-swappable HDD(or 2.5" HDD). Optional 2* 2.5" hot-swappable HDD at the rear | |
| GPU Support: | 4 Dual-slot turbo card | |
| Expansion Slot: | Support 11 full-height PCI cards(multiple rear windows optional) | |
| SGPIO: | Support | |
| System Cooling Fans: | Standard 3× 12038 hot-swappable fans, optional high-speed fans | |
| Smart Fans Speed Contol: | Backboard support | |
| Airduct: | Support for customization optional materials (SGCC/PC/ABS/PE, etc.) | |
| Indicators: | Power ON/OFF *1, HDD *1, NIC *2 , Power Alarm *1 | |
| Front Panel Control: | Power ON/OFF *1, System reset *1, USB2.0 *2/USB3.0 *2 | |
| Rails: | Slide Rail Toolfree guide rail (optional) | |
| Carton size: | 860 x 565 x 305 mm | |
| Net Weigh: | 14 kg | |
| Gross Weigh: | 19.1 kg | |
| Operaing Temperature: | 10°C-35°C (without direct light); extended operating temperature: 5°C-40°C (restrictive configuration satisfied); storage temperature: 20%-90% | |
| Transportation & Storage Temperature: | -40°C-70°C | |
