4U Rackmount Chassis- OC450-Y
• Adaptive Cooling – Configurable fan positions
| • Military Security – Lockable access + reinforced 1.0mm SGCC steel
| • Future Expansion – 14-slot industrial backplane option
| • Universal Compatibility – ATX motherboards & PS2 PSUs
Description
Package Information
Inquiry
| Model: | OC450-Y |
| 4U Rackmount Chassis: | 450 (D)*427 (W)*177 (H) mm |
| Material: | 1.0 mm SGCC |
| M/B Form Factor: | Support mainboard size up to 12″ x 9.6″ |
| PSU Form Factor: | Standard PS2 power supply |
| HDD and FDD Bit: | 8* 3.5″ HDD, 1* 3.5 ″FDD bay |
| CD-ROM Bit: | 3* 5.25″ optical drive bay |
| Expansion Slot: | 7-slot rear panel, 14-slot industrial rear panel optional |
| System Cooling Fans: | 1* 12025 fan, 2* 8025 fan |
| Color: | Black(optional) |
| System Control: | Power SW* 1, Reset* 1, Power LED* 1, HDD LED* 1 |
| Application: | Widely used in industrial control and communication etc. |
| Operaing Temperature: | 10°C-35°C (without direct light); Extended operating temperature: 5°C-40°C (restrictive configuration satisfied); Storage temperature: 20%-90% |
| Transportation & Storage Temperature: | -40°C-70°C |
