4U Rackmount Chassis- OC4129-Y
• Sturdy Industrial Build
| • MB Wide Compatibility
| • Strong Cooling Performance
| • Ample Storage Space
| • Flexible Expansion
| • Secure and Accessible Front Panel
| • Rack-Optimized Design
Description
Package Information
Inquiry
| Model: | OC4129-Y |
| 4U Rackmount Chassis: | 650 (D)*430 (W)*178 (H) mm |
| Material: | 1.0 mm SGCC |
| M/B Form Factor: | Standard ISA/PCI/PCIMG industrial backplane or 12″ x 13″ and below the industrial motherboard |
| PSU Form Factor: | Standard PS2 power supply |
| HDD and FDD Bit: | 10* 3.5″ floppy drive bay (compatible with 3.5″ hard drives) |
| CD-ROM Bit: | 3* 5.25″ optical drive bays |
| Expansion Slot: | 7-slot rear panel,14-slot industrial rear panel optional |
| System Cooling Fans: | 2* 12025 fan, 4* 12025 fan |
| USB Interface: | 2* 2.0 USB port |
| System Control: | Power SW* 1, Reset* 1, Power LED* 1, HDD LED* 1 |
| Application: | Storage, Industrial, IoT, Communication, etc |
| Operaing Temperature: | 10°C-35°C (without direct light); Extended operating temperature: 5°C-40°C (restrictive configuration satisfied); Storage temperature: 20%-90% |
| Transportation & Storage Temperature: | -40°C-70°C |
