9U GPU Server Case -OCG9800-10H4-L
• Support E-ATX motherboards and compatible with standard CRPS power modules
• Accommodate up to ten 4090 GPU cards and can be customized according to specific requirements
• Excellent ventilation system
• Handles on both sides for easy transportation and installation
Description
Package Information
Inquiry
| Model: | OCG9800-10H4-L |
| 9U 10GPU Server Chassis: | 445(W) x 800(D) x 400(H) mm |
| Material: | 1.0 mm SGCC |
| Drive Bays: | 4* 2.5" HDD ( NVME backplane) |
| Cooling Fan: | 12* 12 cm fan （12038 chassis fans *6/ GPU reinforcement fans *6） |
| Dual-port Cards: | 5 pieces of 8654-8i dual-port cards |
| GPU Riser Card: | 10 pieces of GPU riser card |
| M/B Form Factor: | Support motherboard size up to E-ATX (12" x 13") |
| PSU Form Factor: | 4* CRPS redundant power supply boards |
| Power: | 1600W CRPS *4 |
| Connector: | 1* USB3.0 |
| System Control: | 1* Power SW, 1* Reset SW, 1* LAN LED, 1* Alert LED |
| Cable: | · 10 pieces of 8654-8i dual-header cables · Motherboard 24pin power supply cable *1 · CPU power supply cable *2 · GPU backplane power supply cable *4 · 4090 VGA card power cable *10 · Hard Disk backplane power cable *1 |
| Operaing Temperature: | 10°C-35°C (without direct light); extended operating temperature: 5°C-40°C (restrictive configuration satisfied); storage temperature: 20%-90% |
| Transportation & Storage Temperature: | -40°C-70°C |
