Tower Case -OCT-S04
• This GPU server chassis is designed for high-density computing, supporting up to four full-length GPUs and dual redundant power systems
> Ideal for AI training, rendering, or data center workloads
Description
Package Information
Inquiry
| Model: | OCT-S04 | |
| Rackmount Chassis: | L550 x W380 x H590 mm; Slide tower type | |
| Main Material: | 1.2 mm high-strength galvanized steel (non-flower zinc plating), 4.0 mm aluminum panel | |
| Surface Treatment: | Case & accessories: black powder coating Aluminum panel: brushed anodized black | |
| Front Panel: | Power ON/OFF *1, System reset *1, Type-C *1, Audio jack *2, USB3.0 *2 | |
| System Cooling Fan: | Support 2* 360mm radiator mounts (supports 6* 120x38mm fans); top panel upports 6* 120x38mm fans, rear window supports 2* 92x25mm fans | |
| Drive Bays: | Support 4* 3.5"/2.5" hot-swap HDD/SSD modules; compatible with SAS, SATA, U.2 drives | |
| M/B Form Factor: | 12" × 13" (305 × 330 mm) or smaller motherboards | |
| PSU Form Factor: | 2* standard ATX or CRPS redundant power supplies; dual power synchronization supported | |
| GPU Slots: | Support up to 4 GPUs (3090/4090/5090 or similar cards), length 220–360 mm | |
| CPU Cooler Height Limit: | 160 mm | |
| Packaging Method: | Case + PE bag + pearl cotton + accessory box + outer carton | |
| Carton Size: | L700 × W500 × H660 mm | |
| Operaing Temperature: | 10°C-35°C (without direct light); extended operating temperature: 5°C-40°C (restrictive configuration satisfied); storage temperature: 20%-90% | |
| Transportation & Storage Temperature: | -40°C-70°C | |
Case + PE bag + pearl cotton + accessory box + outer carton
